Edelbrock Victor Jr Intake Manifold - 28455
- Part #
- 28455
- Line:
- EDB
Product Information
- Warranty: Manufacturer's Defect Warranty
- Unit of Measure: Each
- UPC: # 85347284559
- Finish: Satin
- Material: Aluminum
- Style: Racing
- Head Type: Standard
- Range (RPM): 3500 To 7500 RPM
- Gasket Or Seal Included: No
- EGR Compatible: No
- Engine Make/Size: Chevrolet Small Block LS1
- Front Height (in): 6 Inch
- Rear Height (in): 6 Inch
- Single Or Dual Plane: Single
Applications for this Product
- This product is universal and applies to all vehicles.
Detailed Description
Intake Manifold;
Edelbrock part number 28455 Victor JR. LS3 intake manifold is designed for Gen IV LS engines equipped with LS3, L92 and L76 cylinder heads. This manifold is for EFI racing applications operating between 3500-7500 rpm. This manifold uses a standard square bore throttle body flange that is compatible with both Edelbrock EFI intake elbows with single bore 90mm throttle body or four-barrel number 4150 throttle bodies. This intake has additional bosses and machining that allow for the use of fuel injectors when combined with the number 3638 fuel rail kit (sold separately). Designed For 3500 To 1500 RPM Performance. Includes Electronic Control Module part number:[91237]. Gen IV LS Engines With L92 Heads.
