APS

MSD Ignition APS Starter - 5095

Part #
5095
Line:
MSD

Product Information

  • Warranty:  1 Year Limited Warranty
  • Unit of Measure:  Each
  • UPC:  # 85132050956
  • Color: Red
  • Design: Gear Reduction
  • Adjustable Mounting Block: Yes
  • Direct Drive: Yes
  • Gear Reduction Ratio: 4.40:1
  • Maximum Recommended Compression Ratio: 18:1
  • Solenoid Attached: Yes
  • Starter Type: Armature
  • Bolts Included: Yes
  • Application: Chevrolet Small And Big Block
  • Shims Included: Yes
  • Mount Material: Billet Aluminum

Applications for this Product

  • This product is universal and applies to all vehicles.

Detailed Description

Starter; Chevrolet;

Our advanced power system line has grown to include starters. Our new APS starter is designed to crank over the highest compression engines on a hot day in Death Valley. Not that too many race cars are sitting in Death Valley, but it's good to know that you have the oomph to make it happen. The APS starter features all new components beginning with a three horsepower motor. This power is used to crank over the reduced 4.4:1 gear set to deliver great torque to the engine's ring gear to get the engine turning. The armature is balanced during assembly and is guided by two ball bearings for smooth engagement and thousands of starts. The downsized housing clears most headers and oil pans, but just in case, we made the billet mount so it can be clocked in different positions to help in tight applications. The assembly is powder coated MSD red and will stay looking good, even though it's underneath your car.

  • Mount Can Be Clocked To Assist In Mounting
  • Downsized design helps clearance issues w/oil pans and exhaust
  • Ball bearing supported armature and pinion gear
  • 3 Hp Motor Provides Power For High Compression Engines
  • Gear reduction of 4.4:1 improves torque for great cranking
